SMY F1 V3 Hyper-Flash Rear Brake Light - Smoked w/ DRL White Light Bar (11-14 WRX/STI)
$95.00
SKU
SMY-F1V3-SMWH-GR
This beautiful rear brake light comes with 8 Red LEDs and a Red trapezoid light bar that is the daytime running light function. The 8 LEDs in the center are both a hyper flashing F1 style brake light or a solid brake light which can be quickly changed from the driver's seat.
Features:
- Center 8 LEDs if the F1 hyper flashing light. 15 blinks each time the brake pedal is pressed
- DRL Light Bar lights up red when your marker lights are engaged (first click on headlight stalk)
- 2 Modes easily switched from driver seat (NEW 1st to market)
- High End plugs to make installation a breeze
- Clear Lens w/ Smoked Background & White Light Bar
- CREE Bulbs
Modes:
- Mode 1 = Hyper Flash Brake Light - Hyper-Blinks 15 Times
- Mode 2 = Steady Brake Light - No Flashing
- Note: Modes can be switched from driver seat using the brake pedal and headlight switch toggle.
Includes:
- Rear Brake Light
- Mounting Hardware
- Wire Taps
- QR code Installation Instructions Included
2011-2014 WRX STI Sedan:
BRAKE WIRE = Cars Tail Light Harness - Red w/ White Stripe (tap with Blue from RBL)
NEUTRAL WIRE = Cars Tail Light Harness - Black (tap with Black from RBL)
DRL WIRE = Cars Tail Light Harness - Black w/ White Stripe (tap with Red from RBL)
Applications:
2011-2014 WRX Sedan
2011-2014 STI Sedan
| Year Fitments | Subaru WRX | Subaru STI |
|---|---|---|
| 2011 | ✓ | ✓ |
| 2012 | ✓ | ✓ |
| 2013 | ✓ | ✓ |
| 2014 | ✓ | ✓ |
WARNING: Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently when servicing your vehicle. For more information go to P65Warnings
| SKU | SMY-F1V3-SMWH-GR |
|---|---|
| Brand | SMY Performance |
