IAG 950 EJ25 Closed Deck Long Block with IAG 950 Heads
A "DROP-IN" SOLUTION
The IAG Performance Hand-Built Subaru EJ25 Closed Deck Long Block Engine Packages are a complete, valve cover to valve cover, crate engine. These engines offer significant ease of installation for customers seeking a complete "drop-in" engine package for their WRX, STI, Forester XT or Legacy GT. The Long Blocks feature a combination of our proven IAG Performance 950 Closed Deck Short Block and IAG 950 Cylinder Head packages, along with other race-proven components to complete the assembly. When paired with our Long Block Installation Packages, you have a true plug-and-play solution to get you back on the road, FAST! All components included are BRAND NEW and there is NEVER A CORE CHARGE required.
BUILT WITH 100% NEW COMPONENTS
The IAG 950 package is ideal for clients looking for an engine package to support up to 950 BHP applications. The IAG 950 Long Block features our IAG 950 Closed Deck Short Block that utilizes a brand new EJ20 or EJ25 Subaru case that is converted to closed deck and is bored and honed to 92.5 or 99.75mm. The IAG 950 block features 14mm head stud machining, as well as our Fire-Lock™ gasket solution that is loosely derived from diesel technology where a counterbore step is machined around each cylinder bore allowing specially sized fire rings to drop into the machined area and head gasket bores. The combination of the alloy compression shims and gaskets assure maximum sealing for a Subaru EJ20 or EJ25 turbocharged engine. The IAG 950 internals include IAG-Spec JE FSR 2618 forged pistons, .250" / .906" H13 pins, IAG-Spec Tuff H-Beam +2mm connecting rods with ARP 625+ rods bolts and an OEM STI crankshaft. The block is then paired up with our IAG 950 Fully CNC Ported Cylinder Heads to deliver maximum flow for high horsepower applications. The heads start as brand new Subaru OEM cylinder head castings that are CNC machined and resurfaced. The heads are outfitted with GSC valve train components, consisting of +1mm oversized intake and SuperAlloy exhaust valves, IAG Beehive Springs, as well as GSC Billet Stage 2 camshafts. To complete the package, we add an IAG / ARP 14mm head stud set and all the required gaskets for the final valve cover-to-valve cover assembly.
As low as
$12,999.99
Only %1 left
SKU
IAG-ENG-L950
IAG (Integrity Auto Group) was established in 2004, initially selling high quality used performance cars. Within a year and a half, IAG sold over 200 Subaru WRX / STI’s. Our clients began requesting us to provide performance products and services for their Subaru’s, which we quickly catered to. IAG extended these services and parts nationally by 2007. Fast forward to 2019, IAG Performance is known as a leader in the automotive performance industry (specifically Subaru) and carries an impeccable reputation among our clients and peers.
IAG 950 EJ20 2.0L or EJ25 2.5L LONG BLOCK INCLUDES
IAG 950 Closed Deck EJ25 Short Block:
- Case Halves -Converted to Closed Deck using brand new Subaru OEM case halves, bored and honed to 99.75mm.
- Fire-Lock -IAG Fire-Lock™ receiver groove machining, latest solution to prevent head gasket failure on high horsepower and high boost Subaru's - *IAG Fire-Lock™ head gaskets required
- Head Studs -Machine Case for 14mm head studs - *Head studs are sold separately
- Pistons -IAG-Spec JE FSR 99.75mm 2618 Forged Pistons, Electroless Nickel Plated Tops & Ring area, Ring Set, .250" / .906" H13 Wrist Pins, Clips, (Perfect Skirt Coating and Offset Wrist Pins)
- Connecting Rods -IAG-Spec Tuff H-Beam +2mm / ARP 625+ Rod Bolts.
- Rod / Main Bearings -ACL or King Race bearings.
- Crankshaft -Standard New Subaru Nitride Treated 2017+ STI Crankshaft.
- Case / Main Bolts -Standard FHI Subaru case bolts.
IAG 950 CNC Ported Cylinder Heads:
- Heads - Brand New Subaru OEM WRX STI Cylinder Head Castings
- Machine Porting - CNC Ported Intake and Exhaust Runners
- Intake Valves - GSC 37mm (+1mm) Intake Valves
- Exhaust Valves - GSC 33mm (+1mm) SuperAlloy Exhaust Valves
- Springs / Retainers - GSC Beehive Valve Springs & Retainers
- Guides - GSC Maganese Valve Guides
- Valve Seals - GSC Valve Stem Seals
- Lifters - OEM Lifter Buckets
- Camshafts - GSC Stage 2 Billet Camshafts
- Multi-Angle Valve Job
- Machined Cam Lobe Clearance
- Drilled For 14mm Heads Studs
- Resurface
- Ultrasonic Cleaning
- Final Lash
Gaskets, Hardware & Accessories:
- Head Studs - IAG / ARP 14mm Set
- Head Gaskets - IAG Fire-Lock™
- Valve Cover Gaskets - OEM
- Cam Seals - OEM
- Valve Covers - OEM
- Wrist Pin Seal, Rear Main Seal & Separator Kit
- Crankshaft Woodruff Key
*All IAG short blocks are balanced and blueprinted.
Shipping:
All IAG Longs Blocks are crated and shipped by freight trucks which include lift gate service. A flat rate shipping charge of $399.99 applies to the lower 48 US states (Prices subject to change without notice). Please contact us for a shipping quote to Hawaii, Alaska, and Internationally.
WARNING: Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently when servicing your vehicle. For more information go to https://www.P65Warnings.ca.gov/passenger-vehicle.
| SKU | IAG-ENG-L950 |
|---|---|
| Brand | IAG Performance |
